wired cloud IP surveillance camera HD 1080P plug&play night visions IR ip camera board

FOB Price

USD $35 - $70 / Piece

1 Piece(Min.Order)

Supply Ability 3000 Piece / Pieces per Month
Port shenzhen
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Guangdong, China	Brand Name:	ENSTER	Model Number:	EST-IPH5692
Type:	IP Camera	Style:	Bullet Camera	Sensor:	CMOS
Technology:	NetWork	Special Features:	Waterproof / Weatherproof

Product Description

feature:

*IP66 Waterproof Bullet Camera
*Externally adjust for Zoom&Focus
*Lens:Varifocal 2.8-12mm
*IR LED: 42pcs IR LED
*IR Range:40m
*3-Axial Anti-Cut Bracket
*Power: DC12V. POE optional( Extra $4)
*Support more than 20 languages
*Mobile Phone View
*Support P2P Function/DDNS
*Motion Detection
*Free CMS,Support ONVIF/RTSP

specification:

model No	EST-IPH5692
camera type	IP camera
system	Embedded RTOS design
camera	effective pixels	2.0 mega pixels
		stream:19201080;1280720
		Sub stream:704*576
	Frames Rates	PAL:25fps(19201080)/(1280720)
	Frames Rates	NTSC:30fps(19201080)/(1280720)
	Image Sensor	1/2.8" SONY CMOS sensor with ICR
	DSP	Dual core 32-bit DSP
	DSP	(Hi3516)
	Min. Illumination	Color 0.01LuxF1.2
	Min. Illumination	B/W 0.001 LuxF1.2
	Adjust Parameters	DWDR,BLC,DNR,AE,AGC,D&N,Mirror,Flip,etc.
Video	Compression	H.264 Main profile
	Stream	support dual stream,AVI format
	Bit Rate	support 0.1M ~8Mpbs bit rate
	Bit Rate	adjustable
Audio	Frame Rates	support 1~30fps adjust
	Input and output	1ch input( micphone),1ch output( Speaker&micphone) Optional
	Compression	G.711 compression,support two-way audio intercom
	Compression	support audio and video synchronized output
Alarm	Types	Motion Detection, Video Blind , Video Loss
Network	WEB Browser	Support WEB remote config( IE, Safari, Google Chrome, Firefox etc.)
	Smart Phone	mobile remote Monitoring (iPhone,Android,Windows Mobile,BlackBerry,Symbian)
	CMS Software	Uniform CMS Software(multiple devices management system)
	Cloud P2P	,MYEYE platform and other program,Offer SDK
	Network	1 * RJ45,10/100M,Support RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP/SMTP
	ONVIF	Support (ONVIF 2.0)
	POE	Support(optional)
Genera	Language	20 kinds of languages such as English, Finnish, French, German, Greek,Italian, Japanese, Polish
	Language	Portuguese, Russian, Spanish, Thai, S-Chinese, T-Chinese and Turkish
	IR Cut Filter	Set of double light switch IR-CUT filter
	Lens Mount	Varifocal Lens 2.8-12mm
	Infrared Luminary	42pcs IR LED
	Infrared Wavelength	850 nm
	IR distance
	Waterproof	IP 66
	I/O Connector	1DC Connector ,1 RJ45(10/100M Network)
	Supplied Voltage	DC12V/PoE(802.3af/820.3at)
	Power consumption	IR On: 600mA max., IR Off: Less than 200mA

...
