food processing machinery aluminum wire double clipping DKLC-II

Specifications

1.speed:130times/min
2.weight :400kg
3.aluminumwire double-clipper

DLJL—III Double – clipping machine

It is our newest product ,which is researched and developed by ourselves .It is rational structure , reliable performance and more  effectively .it is the alternative product

Of pneumatic double-clipping machine . servomotor droved and PLC controlled .sample operation .tightly sealed .it suits for the nylon, contract and PVDC

Sausage casing .

According to the different types of sausage casing we should adjust the model and

Aluminum wire .The main parts are made of stainless steel .In addition .it is waterproof  and washing  conveniently .



Model	Power (kw)	Clip model (mm)	Casing(mm)	Speed (times/min)	Pressure (mpa )	Weight (kg)	Dimension(mm)
DKJL-II	3.5	2.1~2.7	35~100	120	0.5~0.6	400	1150×650×1500
DKJL-III	3	2.1~2.9	35~120	130	0.5~0.6	400	1520×900×1500
