Home > Manufacturing & Processing Machinery > Cutting & Fold-bend Machine > Bending Machine > WC67Y Series Goose Neck Press Brake Tooling

WC67Y Series Goose Neck Press Brake Tooling

Name: WC67Y Series Goose Neck Press Brake Tooling
Brand: haiwei
SKU: 100732871
Availability: InStock

WC67Y Series Goose Neck Press Brake Tooling thumbnail-1

WC67Y Series Goose Neck Press Brake Tooling photo-1

US$ 50,000 - 60,000 MOQ: 1 Piece

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Jiangsu, China

Brand Name:

haiwei

Contact Supplier Request Quote Chat Now

Nantong Teli Forming Machine Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Jiangsu, China

Brand Name haiwei

Model Number WE67K-300/4000

Machine Type Press Brake

Raw Material Sheet / Plate Rolling

Material / Metal Processed Stainless Steel

Power Hydraulic

Automation Automatic

Extra Services End Forming

Certification ISO 9001:2000

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1,standard top and down dies
2,Atos valves/siemens parts
3,DA41 cnc system

Functions and Characteristics

WC67Y series goose neck press brake tooling

1. Steel-weldes construction,bibration to eliminate stress,with high strengh and good rigidity.

2. Hydraulic topdrive,steadiness and reliability.Mec hanical stop,steel torsion bar to maintain

sychronization,high precision.

3. Motorized adjusting device of backgauge and rams stroke,fine adjusting by handwheel,num

erical display.

4. Deflection compensation unit installed on the top die.Manual crowned bottom die holder is

adopted for the machine above 250ton slength4000mm Length.

5. Travel limit protection.Full machine guarding with safety interlocke

No	Name		Data	Unit	Remarks
1	Nominal pressure		3000	KN
2	Length of working table		4000	mm
3	Plate strength		≤450	N/mm2
4	The distance of column		3200	mm
5	Ram stroke		250	mm
6	Max opening height		515	mm
8	Depth of throat		400
8	Ram speed	Free	60	mm
		Running	8	mm
		Return back	60	mm
9	Main	Type	Y200L12-6 B5
		Power	22	KW
		Speed	970	rpm
10	Max pressure of system		25	Mpa
11	Axial pump	Type	63MCY14-1B
		Speed	63	L/min
		Pressure	31.5	Mpa
12	Out size	Length	4250	mm
		Width	2300	mm
		Height	4200	mm
13	Weight		22500	kg

Usage

The hydraulic press brake can be applied to boiler tank, air conditioning channels, sheet metal cover, cone making and other aluminum and steel fabrication, marine and ship building, pressure vassals and wind mills.
