Home > Manufacturing & Processing Machinery > Cutting & Fold-bend Machine > Bending Machine > Hydraulic Press Brake Machine

Hydraulic Press Brake Machine

Name: Hydraulic Press Brake Machine
Brand: haiwei
SKU: 100732695
Availability: InStock

Hydraulic Press Brake Machine thumbnail-1

Hydraulic Press Brake Machine thumbnail-2

Hydraulic Press Brake Machine thumbnail-3

Hydraulic Press Brake Machine thumbnail-4

US$ 85,000 - 120,000 MOQ: 1 Piece

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Jiangsu, China

Brand Name:

haiwei

Contact Supplier Request Quote Chat Now

Nantong Teli Forming Machine Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Jiangsu, China

Brand Name haiwei

Model Number WE67K-600/6000

Machine Type Press Brake

Raw Material Sheet / Plate Rolling

Material / Metal Processed Stainless Steel

Power Hydraulic

Automation Automatic

Extra Services End Forming

Certification ISO 9001:2000

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1,standard top and down dies
2,Atos valves ,siemens parts
3,DA41 cnc system

No	Name		Data	Unit	Remarks
1	Nominal pressure		6000	KN
2	Length of working table		6000	mm
3	Plate strength		≤450	N/mm2
5	Ram stroke		300	mm
6	Max opening height		650	mm
7	Depth of throat		600	mm
8	Max bending thickness		16	mm
9	Distance of column		5420	mm

8	Ram speed	Free	80	mm
		Running	7	mm
		Return back	45	mm
9	Main	Type	Y280S-6 B5
		Power	45	KW
		Speed	980	rpm
10	Max pressure of system		26	Mpa
11	Gear pump	Type	NB5-G100F
		Speed	100	L/min
		Pressure	32	Mpa
12	Out size	Length	6300	mm
		Width	2800	mm
		Height	3600	mm
	Machine weight		60000	Kg

Performance:

3-1 All steel welded structure, vibrating treatment of aging for removal of internal

stress with high strength and good rigidity.

3-2 Electrohydraulic synchronization of mechanical limit stopper balance with high

precision.

3-3 Integrated hydraulic transmission system, large range of speed regulation to

transmission of the sliding block, stable and reliable performance.

3-4 Rear stopper and the sliding block have electrical adjustment for their stroke

with manual fine tuning and digital indication.

3-5 Adjustment mechanism of sliding block independent from oil cylinder assembly

to enhance sealing effect upper mold is fitted with titling warp offset mechanism

Usage

The hydraulic press brake can be applied to boiler tank, air conditioning channels, sheet metal cover, cone making and other aluminum and steel fabrication, marine and ship building, pressure vassals and wind mills.
