2X4 40W 4500lm Pure White Linear Magnetic
with UL DLC
ILEDING’s LED Linear Troffer Retrofit Kit Strips are economic LED replacements
for 1’x4’, 2'x2' and 2'x4' existing recessed troffers in drop-in ceilings. The kits are
easily field installed using simple hand tools with minimum modification to the
existing housings.
Feature
• Voltage:100-277V/60Hz
• Lumen Efficiency:112-125Lm/W LED,96-105Lm/w Luminaire
• Power Factor:up to 0.998
• CCT:3000, 3500, 4000, 5000K
• CRI (Ra):82 nominal
• Mounting method:Magnetic led strips and driver, quick-connect
• Replacements: Retrofit 2’ x 2’, 1’ x 4’, and 2’ x 4’ “troffer” style fixtures
• Dimmable is also available
| Rated Power |
LED Strips Q’ty x Length |
Model No. | Lumen | Ra | CCT | Beam Angle |
Fits Fixture | Mounting |
| 20W | 2pcs x 550mm | RG-22TR20WXXK | 2500 | 82 | 5000K | 140° | 2’ x 2’ Troffer | Magnetic |
| 40W | 2pcs x 550mm | RG-22TR40WXK | 4500 | 2’ x 2’ Troffer | Magnetic | |||
| 40W | 2pcs x 1100mm | RG-14TR40WXXK | 4500 | 1’ x 4’ Troffer | Magnetic | |||
| 40W | 2pcs x 1100mm | RG-24TR40WKKX | 4500 | 2’ x 4’ Troffer | Magnetic | |||
| 40W | 4pcs x 550mm | RG-24TR4S40WXXK | 4500 | 2’ x 4’ Troffer | Magnetic |
Company Profile
We supply home lighting, engineering lighting, electrical and other lighting fixtures.
Home lighting products includes:ceiling light,dining-room light,down light,spotlight,wall light,
mirror-front light,eye-protection light,T5 holder, compact fluorescent lamps etc;engineering
lighting products includes:light source,electrical parts,ceiling light,low voltage spotlight,high
power spotlight,LED troffer retrofit kits, IP65 LED vapor tight light,down light,lamp panel,
holder, metal halide lamp,etc. Our attention to the technical and quality control makes us
unique.
