high quality wood cnc router more popular wood cnc router price 1300mm*2500mm two spindle cnc
Functional Characteristics
1. Vacuum table with 6 vacuum zones, which can absorb different size materials, no oil vacuum pump, high suction, more convenient, stable capability.
2. HIWIN square orbit, double slippers, bearing heavy, working steadily, high precision, and long life time, import ball screw, high precision for cutting.
3. Double 3.0 kw Italy HSD Air Cooling Spindle, Max speed is 25m/min. With water cooling spindle highly upgrade the processing speed.
4. The optional equipment for spindle is Japan imported high power water cooling motor (Japan NSK bearing) high speed spindle, stable capability.
5. Unique intelligent budget principle, fully develops the potential of the motor and lead to high processing speed, the synchronization of curves and straight lines, smoother curves.
6. Well compatibility: CAD/CAM designing software e.g. Type3/Artcam/Castmate/Ucancam etc.
Apply to industry and materials
Furniture industry: the cabinet door, wooden door, solid wood, plate, doors and Windows, tables and chairs. Decoration industry: screen, wave plates, large wall hanging, advertising board, logo production.
Performance index
Model NO | YS-1325C-2 Wood CNC Router |
Table Size | 1440×3000mm |
X Y Z Traveling Area | 1300x2500*200mm |
Table Structure | Vacuum Table |
X Y Transmisson | Rack Gear |
Z Transmission | Germany Neef Ball Screws |
X Y Z Guide Rail | TAIWAN HIWIN Square Rail |
Spindle Power | Double 3.0 kw Italy HSD Air Cooling Spindle |
Driving System | Japanese YASKAWA Servo Motor |
Max Spindle speed | 18000r/ min |
Max Traveling speed | 45m/s |
Max Working speed | 38m/s |
Processiong Accuracy | ±0.025mm |
Reposition Accuracy | ≤0.025mm |
Working Voltage | 380V 50Hz |
Work-holding | T-slot Clamping |
Processor | Windows /100MHz |
Interface | PCI |
Command | G*.u00*.mmg*.plt |
Operation system | DSP |
Power(not include the spindle) | 500W |
Net weight /Gross Weight | 1100KGS /1200KGS |
Package dimension | 3200*1840*1900mm |
Working sample
machine part
other machine
♦ 24 hours technical support online.
♦ We offer detailed User Manual together with machine
♦ We offer machine operation video free
♦ We offer training in our factory free
♦ Engineers available to service machinery overseas
Shandong Yishun CNC Machinery Co., Ltd. is the manufacture of CNC Router, Plasma Machine and Laser machinewith well-equipped testing facilities and strong technical force. With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in many industries. Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs. We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success.
Looking for agents all over the world!
