Home > Products > 5.0ton wheel loader > mini wheel loader heavy equipment zl50
mini wheel loader heavy equipment zl50
- 3000 Unit / Units per Month
- QINGDAO
- T/T Credit Card
Product Details
Place of Origin: | Shandong, China | Brand Name: | Laigong | Model Number: | ZL50 |
Condition: | New | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
5ton wheel loadermini dozer
agricultural farmland equipment
1 year warranty
mini wheel loader heavy equipment zl50
5ton wheel loader
mini dozer
agricultural farmland equipment
1 year warranty
Main Descriptions
1. Antirust paint with all color, streamlined appearance, beautiful and elegant, and can attach different tools such as: coal bucket, pipe fork, grass fork, stone bucket… to realize multifunction. Wildly used building site, coal mines, brickyard, stone materials factory, urban construction and so on.
2.WeiChai Steyr Engine, OTR Tires, Bigger and stronger chassis.
3.Bucket that can be set level automatically, "Z" type turning bucket structure, to realize the enormous shovel digging forces.
4.Dual pump meeting hydraulic system can economize on oil 10%,
5.Central articulated frame and load sensing hydraulic steering gear, short turning radius and flexible turning, can work in narrow site and has sound off-road performance, good traffic ability and larger traction.
6.Cabin made by double-layer1.4mm steel plate with strong steel frames inside.
7.A fully enclosed cabin and the seats have the functions of vibration reduction and easy adjustment from 6 directions, offers the driver a comfortable and wide view.
Applications
Wheel loader is mainly used to shovel or transfer loose soil, sand, cinder, garbage and other loose materials in the road building, urban construction, It also can be used in dozing, digging, scraping, stacking, lifting, dragging and other operations.
More photos
Specifications
Model: | Unit | ZL50F |
Total weight | Kg | 16500 |
Bucket capacity | m 3 | 3 |
Rated load | Kg | 5000 |
Movable arm lifting time | S | ≤ 6.5 |
Three item time | S | ≤ 11.5 |
Max digging force | KN | 165 |
Min turning radius | mm | 6770 |
Max slope angle | ° | 28 |
Dumping height | mm | 3200 |
Dumping reach | mm | 1180 |
Overall dimensions(L×W×H) | mm | 7840×2950×3450 |
Engine model | WD10G220E21 | |
Engine rated power | KW | 162 |
Fuel tank capacity | L | 280 |
Hydraulic oil tank capacity | L | 210 |
