Home > Products > bottle blowing machine > small bottle plastic blow moulding machine
small bottle plastic blow moulding machine
- 20 Set / Sets per Month
- xingang port
- T/T
You May Like
Product Details
| Condition | New | Application | Other, Bottle, bottles | |
| Plastic Processed | Other, PP, PE | Blow Moulding Type | Extrusion Blow Moulding | |
| Automatic | Yes | Place of Origin | Hebei, China | |
| Brand Name | zhongyi, zhongyi | Model Number | xsj-1, sj-45 sj-55 sj-65 | |
| Voltage | 380v | Power(W) | 17KW | |
| Dimension(L*W*H) | 3300*1200*1500 | Weight | 1800KG | |
| Certification | patent | Warranty | one year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
small bottle plastic blow moulding machine1. ours is a manufacture company
2. fast-speed
3. simple operation
4. save energy
small bottle plastic blow moulding machines:
We have the patent: 1. rotary-type automatic plastic blow mold machine patent number: ZL 2006 2 0160012.1 2.automatic plastic blow mold machine s device of cutting the material folder within the mould. Patent number: ZL 2005 2 0123986.8
brand | zhongyi |
product | Fully automatic plastic blow molding machine |
type | Xsj-1 |
advantages | Fast-speed, simple operation, save energy and the price is cheap |
The composition | Extrusion, molding, orifice-cutting, removing the tailing |
What goods it can product | Middle-hollow bottles such as square milk bottles,round milk bottles, popsicle bottles, jelly bottles, medical medicine bottles, pesticide bottles, cosmetic bottles, huoxiangzhengqi water bottles, eyedrop bottles, test-tube, straw, plastic straw etc. |
Extruder Technical Parameter List | |
Screw diameter mm | 55 |
Long-radius rate | 1:25 |
Extrusion electric machinery power kw | 7.5 |
Screw rotation speed rpm | 20~65 |
Plasticizing capacity kg/h | 35 |
Heating power kw | 8.8 |
Molding Machine Technical Parameter List | |
Lock mould type | Pneumatic lock mould |
Max moulding strength kg | 700 |
Mould plate dimension(width*height) mm | 130*200 |
Width between mould plate mm | 122 |
Max diameter of the machine | 70 |
Production capacity PCS/day | 30000~80000 |
Blowing pressure Mpa | 0.5 |
Cooling water pressure Mpa | 0.2~0.3 |
Gas consumption quantity m3/min | 0.4 |
Electric machinery power kw | 0.75 |
Parameter list | SJ-45 | SJ-55 | SJ-65 |
Screw diameter mm | 45 | 55 | 65 |
Long radius rate | 281 | 251 | 251 |
Extrusion electric machinery power kw | 5.5 | 7.5 | 11 |
Screw rotation speed rpm | 20-65 | 20-65 | 20-65 |
Plasticizing capacity kg/h | 25 | 40 | 60 |
Heating power kw | 6 | 8 | 11 |
Weight kg | 650 | 750 | 1000 |
Appearance dimension(L*W*H) | 1800×850×1600 | 1900×850×1600 | 2100×850×1600 |
The suitable raw material | PE/PP/PS/PVC | ||
The method of adjusting speed | Frequency conversion | ||
