Name: PG-107 Polarizing Microscope
Brand: PDV
SKU: 100584187

ALL CATEGORIES

PG-107 Polarizing Microscope

Send Inquiry to This Supplier

Mrs. A my

Beijing PDV Instrument Co., Ltd.

Beijing, China

* Message

0/5000

* Email

Get quotes from multiple Verified Suppliers simultaneously.

Model	PG-107
Viewing Head	Sliding Binocular Head at 45°, 360° Rotatable
Viewing Head	Sliding Trinocular Head at 45°, 360°Rotatable
Eyepiece	Eyepiece WF10×/ 18 with Scale of Crosshair
Eyepiece	Eyepiece WF10×/ 18
Objective	Strain free Achromatic Objective 4×,10×,40×
Nosepiece	Toward Quadruple Nosepiece, Center Adjustable
Analyzer	Rotatable Analyzer with Gradation 0°-90°
Bertrand Lens	Bertrand Lens, Sliding in/ out of Optical Path
Optical Compensator	λ Slip(first class red)
	1/ 4λ Slip
	Quartz wedge
Revolving Round Stage	Diameter Φ160mm, Graduated in1° Increments, Minimum Resolution 6’ when using Vernier Scale
Condenser	Abbe Condenser with Iris Diaphragm & Filter
Focusing	Coaxial Coarse & Fine Adjustment, Range 28mm, Fine Division 0.002mm
Polarizer	Sliding in/ out of Optical Path, Located on the Top of Collector
Illumination	6V/ 20W Halogen Lamp, Brightness Adjustable

PG-107 Polarizing Microscope

Product Details
