The product intro of electric stacker FBT series
1.ZAPI Full-AC controller,imported ZF gear-box,high efficient, low noise.
2.Multi-functional, flexible vehicle,it can be used at narrow aisle as well as the wide one.
3.All the moves of fork can be finished by manual mode.
4.The operation such as goods stacking preparation and location can be done by human-computer interface at auto mode.Moreover,if longitudinal location meets the requirement ,it can automatically stack goods.
5.Human-computer interface not only can be used as a input device, but also shows the real time vehicle data such as position of wheels and forks, weight of goods.
6.It is equiped with video display system,operator can closely see the goods’ type, pattern and position no matter where the fork is.
The specification of electric stacker FBT series
| Model | unit | FBT13 | FBT15 | |
| Drive mode | electric | |||
| Rated capacity | kg | 1300 | 1500 | |
| Load center distance | mm | 600 | 600 | |
| Standard mast extended height | mm | 7500 | 7000 | |
| Turning angle | Deg | 180° | 180° | |
| Max turning radius | mm | 2175 | 2500 | |
| Body length(without fork) | mm | 3428 | 3788 | |
| Body width | mm | 1210/1520 | 1210/1520 | |
| Mast lowered height | mm | 3610 | 3455 | |
| Overhead guard height | mm | 2461 | 2461 | |
| Steering type | electronic steering | |||
