Home > Consumer Electronics > Two Way Radio > Handheld Two Way Radio > Kenwood TM-271A 144mhz 2 Meter Handheld Radios

Kenwood TM-271A 144mhz 2 Meter Handheld Radios

Kenwood TM-271A 144mhz 2 Meter Handheld Radios photo-1
US$ 100 - 150 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Japan
Brand Name:
Kenwood
Model Number:
TM-271A
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Japan
Brand Name Kenwood
Model Number TM-271A
Type Vehicle Mouted
Dimensions 160 x 43 x 137 mm
Frequency Range TX:144-148 MHz RX:136-174 MHz
Storage Channel TX:144-148 MHz RX:136-174 MHz
Talk Range 5-10km

Kenwood TM-271A 144mhz 2 meter FM transceiver

Product Description

Kenwood TM-271A 144mhz 2 meter handheld radios

Frontiers are not for the meek. It takes a rugged 4WD vehicle to meet the challenges of the wilderness. And KENWOOD's new TM-271A is built just as tough. This compact, MIL-STD-compliant transceiver delivers powerful mobile performance and such advanced features as multiple scan functions and memory names, as well as NOAA Weather Band & emergency alert reception*. On or off the road, you can always enjoy the sophistication of high-quality audio. Illuminated keys and a large LCD with adjustable green backlighting for easy operation day or night. The TM-271A is the ideal companion for all your travels.

  • HIGH RF POWER OUTPUT (60W)
  • US MIL-STD 810 C/D/E/F & EUROPEfS E-MARK
  • ALPHANUMERIC LCD AND ILLUMINATED KEYPAD
  • DTMF MICROPHONE
  • HIGH-QUALITY FRONT SPEAKER
  • MULTIPLE SCAN FUNCTIONS
  • 200 MEMORY CHANNELS PLUS 1 CALL-CHANNEL
  • MEMORY NAME FUNCTION
  • CTCSS & DCS ENCODER/DECODER
  • HIGH FREQUENCY STABILITY
  • 1200/9600BPS HIGH-SPEED DATA COMMUNICATIONS

High Rf Power Output (60w)
Despite its size, the TM-271A can provide an impressive 60 watts of RF power, with a choice of High/Low output.
Weather Alert/Rx (US only)
This transceiver is capable of receiving the NOAA Weather Band and responding to emergency transmissions such as storm warnings by emitting an audible alert tone.



Dtmf Microphone
The TM-271A is supplied with a DTMF microphone as standard.
High-Quanlity Front Speaker
The large oval (2.28" x 1.38") speaker mounted in the front panel provides excellent clarity.
200 Memory Channels Plus 1 Call-Channel

Each of the 200 memory channels can be used to store, transmit, and receive frequencies independently. Additionally, memory data can be edited and stored on your computer using MCP-1A Memory Control software. For details on purchasing an interface cable, consult your local dealer.

Memory Name Function
At-a-glance identification of 100 memory channels is possible with up to 6 alphanumeric characters per channel. Up to 200 channels are available if the memory name function is not used.
Mulitiple Scan Functions
For maximum versatility, the TM-271A offers several scan functions, including VFO (band) scan, all memory scan, program scan, memory group scan (group scan), call scan, tone/CTCSS scan, DCS scan and priority scan, which checks a priority channel every 3 seconds. TO (Time-operated), CO (carrier-operated) and seek scan resume modes are also provided.
Ctcss & Dcs Encoder/ Decoder
The built-in CTCSS and DCS encoder/decoder enables operation of the 42 CTCSS subtone frequencies and 104 DCS subtone codes.

Specifications

  TM-271A
General
Frequency Range TX:144-148 MHz
RX:136-174 MHz
Mode F3E (FM)
Power Requirement 13.8V DC ±15%, negative ground
Current Drain
  Transmit
  Receive
Less than 13.0 A High), less than 8.0 A (Low)
Less than 1.0 A
Operation Temperature Range -20° C ~ +60° C
Antenna Impedance 50 ohms
Microphone Impedance 600 ohms
Frequency Tolerance ±2.5 ppm (-20°C ~ +60°C)
Dimensions (W x H x D)
  (Projections included)
6.30" x 1.69" x 5.39" (160 x 43 x 137 mm)
6.33" x 1.69" x 6.65" (161 x 43 x 169 mm)
Weight 2.6lbs (1.2 kg)
Transmitter
RF Output Power (approx.)
  HI
  LO
60 W
25 W
Modulation Reactance modulation
Maximum Frequency Deviation ±5 kHz
Modulation Distortion Less than 3% (300 MHz ~ 3 kHz)
Receiver
Circuitry Double Conversion Superheterodyne
Intermediate Frequency
  1st IF
  2nd IF
49.95 MHz
450 kHz
Sensitivity (12dB SINAD) Less than 0.18 μV (Narrow: less than 0.22 μV)
Squelch Sensitivity Less than 0.1 μV
Selectivity
  -6 dB
  -60 dB
More than 12 kHz (Narrow: more than 10 kHz)
Less than 30 kHz (Narrow: less than 24 kHz)
Audio Output Power More than 2 W (5% distortion)

KENWOOD follows a policy of continuous advancement in development.
For this reason specifications may be changed without notice
