GH520B Vertical Packing Machine

GH520B Vertical Packing Machine photo-1
US$ 8,500 - 13,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Food, Medical, Chemical
Packaging Type:
Stand-up Pouch, Bags, Film, Pouch
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Food, Medical, Chemical
Packaging Type Stand-up Pouch, Bags, Film, Pouch
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Mechanical
Voltage AC 220V,50HZ
Power 2.5KW
Place of Origin Guangdong, China
Brand Name APM
Model Number GH520B
Weight 650KG
Dimension(L*W*H) 1650x1180x1790mm
Certification CE certification
After-sales Service Provided Engineers available to service machinery overseas
GH520B Vertical Packing Machine


Features



1. Famous brand PLC control system, large touch screen, convenient to operate;

2. Film drawing down system and horizontal sealing controlled by servo motor;

3. Various alarm system to reduce waste;

4. It can complete feeding, measuring, filling, sealing, date printing, charging (exhausting), counting, finished product delivery when it equips with feeding and measuring equipment.

5. It can make pillow bag, gusseted bag, standing up bag, according to customer’s requirements.



Application

Suitable to pack granule, solid state materials, powder and liquid, such as sugar, nuts, beans, coffee, potato chips, puffed food, etc.



Specification



Model

GH520B

Capacity

Max. 50bags/min

Bags size

Length:80---350mm Width:100---250mm

Film width

Max.520mm

Film thickness

0.04-0.09mm

Air consumption

0.8Mpa  0.5m3/min

Power source

1N+PE/50ZH/AC220V/2.5KW

Dimension

L1650 x W1180x  H1790mm

Weight

650kg





GH520B Vertical Packing Machine



GH520B Vertical Packing Machine



GH520B Vertical Packing Machine



Samples:

GH520B Vertical Packing Machine







Shipping Packing:

GH520B Vertical Packing Machine



Certification:

GH520B Vertical Packing MachineGH520B Vertical Packing Machine

Exhibition Information:

GH520B Vertical Packing MachineGH520B Vertical Packing Machine



Welcome to enquiry,thank you !
