Multi-head weigher standup bag packing machine...
Combined parts
1.GH420T vertical packing machine 2.10 or 14 heads combination weigher 3.Z type bucket elevator
4.Vibration feeder 5.Supporting platform 6.Finished product conveyor
Options
1. Chech weigher 2.Metal detector 3.Turntable
Features
1.The machine completes the whole procedure of feeding, measuring, bagging, date printing, charging(exhausting), finished product outputting automatically.
2.High accuracy, high efficiency without crashing the material
Application
Suitable to package fragile materials demanding high accuracy, such as puffed food, crispy rice, jelly, candy, pistachio, apple slices, dumpling, chocolate, pet food, small hardware, medicine, etc.
GH420T standup bag vertical packing machine
Features
1.Attractive bag type to satisfy your high demand.
2.It completes bagging, sealing, date printing, punching, counting automatically.
3.Film drawing down system controlled by servo motor. Film rectifying deviation automatically.
4.Famous brand PLC. Pneumatic system for vertical seal and horizontal seal
5.Easy to operate, low maintenance, compatible with different internal or external measuring device.
Specification
Model |
GH420T |
Packing speed |
Max 40bags/min |
Bag size |
Length:80---280mm |
Front width:60—140mm | |
Side width:30---70mm | |
Width of side seal:5---10mm | |
Bag type |
Block bottom type |
Film width |
Max:420mm |
Air consumption |
0.8Mpa 0.45m3/min |
Power supply |
220V 3.9KW 50HZ |
Weight |
700kg |
