high temperature ptfe mesh belt for conveyor ow price

Specifications

ptfe mesh belt for conveyor
1.Fleet brand
2.heat resistant
3.keep sample same with mass goods

                         ptfe mesh belt for conveyor

As the largest supplier in China, Fleet uses the best imported fine fiberglass or Kevlar as basic weaving material , coated with excellent PTFE resin to produce a variety of ptfe open mesh

 Properties of ptfe mesh belt for conveyor:

 1. Good temperature tolerance,24 working temperature -140 to 360 Celsius degree.

 2.  Non stick,easy to clear adhesives on the suface.

 3.  Good chemical resistance:it can almostly resist most of chemical medicines,acids,alkalis,and salt;fireproof,lower in aging.

 4.  Low coefficient of friction and dielectric constant,good insulating capacity.

5. It can avoid wasting heat and improve drying efficiency for its permeability.

Application of ptfe mesh belt for conveyor:

1. Drying machine for non-woven textile, textile printing, silk-printing and dyeing machine.
2. Shrinking machine for garment fabric, high-frequency and UV dryer.
3. Hot-air dryer, various of food baking, quick-frozen machines.
4. Food processing and packing.
5. Release sheet for sticky products.

 Technical data sheet of ptfe mesh belt for conveyor:



Item No	Mesh size	Thickness	material	Max width	weight	Temperature
M001	1*1mm	0.5 mm	Fiberglass	4000mm	390g/m²	-70-360
M002	2*2mm	0.7 mm	Fiberglass	4000mm	450g/m²	-70-360
M003	4*4mm	1.0 mm	Fiberglass	4000mm	500g/m²	-70-360
M004	4*4mm	1.0 mm	Fiberglass	4000mm	480g/m²	-70-360
M007	4*4mm	1.2 mm	Fiberglass+Kevlar	4000mm	560g/m²	-70-360
M008	4*4mm	1.0 mm	Fiberglass	4000mm	570g/m²	-70-360
M010	4*4mm	1.0 mm	Kevlar	4000mm	460g/ m²	-70-360
M012	4*4mm	1.0 mm	Fiberglass	4000mm	580g/ m²	-70-360
M013	10*10mm	1.0 mm	Fiberglass	4000mm	450g/m²	-70-360
M014	0.5*1mm	0.5 mm	Fiberglass	4000mm	420g/m²	-70-360
M015	2*2.5mm	0.9 mm	Fiberglass	3000mm	470g/m²	-70-360

 Specifications of ptfe mesh belt for conveyor:

1.Mesh size:4*4mm,0.5*1mm,1*1mm,2*2.5mm,10*10mm size

2.Color: brown, black

3.Material:fiberglass +PTFE or Kevlar

4.Jumbo roll: max width 4m

5.Joint style: bull nose jont, Alligator Joint, Metal Clipper joint

Any special requirements please contact us , we can do any size of the goods according to the requirements of customers.



Product pictures:

Joint style:

Full view:

As a manufacturer, strong R&D capacity. high quality, reasonable price and timely service are our advantages.
