Paper Filter KLFC-022
Specifications
*Pleated synthetic polyester filter media*High dust holding capacity
*Reduced pressure drop
*High economic efficiency
paper filter KLFC-022
SPECIFICATIONS
Application: prefilters HVAC, industry, spray booth
Frame: firm cardboard frame
Medium: synthetic+aluminium mesh
Filter class according to EN 779:2002: G4
Maximum final pressure drop: 250Pa
Maximum temperature: 80°C
Maximum relative humidity: 90%
ADVANTAGES
• Straightforward assembly
• Lower pressure drop
• Paper frame, environmental protection, easy recovery ,low cost
•Premium performance and construction
•High loft media increases dust holding capacity
•Provides the highest efficiency available in a panel type filter
•Widely used as a prefilter to extend the life of higher efficiency filters
| Nominal Size | Actual Size | Rated Airflow(CFM) | Nominal Size | Actual Size | Rated Airflow(CFM) |
| WxHxD.inch | WxHxD.mm | WxHxD.inch | WxHxD.mm | ||
| 20x18x1 | 495x445x21 | 1500 | 20x20x2 | 495x495x46 | 2363 |
| 24x10x1 | 595x241x21 | 1000 | 24x20x2 | 595x495x46 | 2839 |
| 24x12x1 | 595x295x21 | 1190 | 24x24x2 | 595x595x46 | 3400 |
| 24x14x1 | 595x343x21 | 1394 | 25x14x2 | 619x343x46 | 2000 |
| 24x16x1 | 595x394x21 | 1650 | 25x15x2 | 619x368x46 | 2210 |
| 24x18x1 | 595x445x21 | 1785 | 25x18x2 | 619x445x46 | 2660 |
| 24x24x1 | 595x595x21 | 2380 | 20x20x4 | 495x495x96 | 2363 |
| 20x10x2 | 495x241x46 | 1200 | 24x16x4 | 595x394x96 | 2261 |
| 20x14x2 | 495x343x46 | 1658 | 24x18x4 | 595x445x96 | 2550 |
| 20x15x2 | 495x368x46 | 1777 | 24x20x4 | 595x495x96 | 2839 |
| 20x16x2 | 495x394x46 | 1870 | 24x24x4 | 595x595x96 | 3400 |
