Lab resin making machine planetary mixer
Lab resin making machine planetary mixer is new and high efficient mixing equipment designed for universities, research
institute and factory lab. The machine consists of low speed agitator and a high speed disperser, has good mixing,reacting,
dispersing, dissolving effect, especially suitable for the dispersing and mixing of solid-liquid, liquid-liquid phase; It’s quite
fit for high viscosity product such as adhesives, silicone, Lithium battery slurry etc. due to its super strong output torque;
The equipment has scraper which can scrape the bottom of the tank without dead corner or residue; also there are extrusion
device and sliding rail to work together with this machine, so that realizing the integrated operation of mixing and discharging.
[Materials Viscosity]: ≤1,000,000 cps
[Production Capacity]: 2-8L
[Applicable Materials]: Various slurries with viscosity less than 1,000,000cps, solid content under 90% such as battery paste,
solder paste, ceramic paste, silicone inks, sealants, structural adhesives, soft cream, jam etc..
High mixing efficiency, wide application
The dual planetary Mixer has two sets of agitators and a set of high speed dispersing shaft revolving around the container
axle and at the same time rotating at high speed, so that the materials are mixed rapidly under the action of strong shearing
and kneading force. Various agitators (blade type, twist type, claw type, frame type etc) are in option based on materials with
different viscosity and different specific gravity.
Safe and convenient operation
Adopt hydraulic cylinder as lifting actuators. Control the mixer up, stop and down through controlling the valve, simple operation
with high stability; with barrel holding device for fixing the tank rapidly to prevent any possible accident due to tank displacement.
There is sliding rail device between the mixing and extruding tank, convenient for moving tanks, realizing the integrated operation
of mixing and discharging.
No residue on the wall, clean discharging
There is scraper on the planetary frame rotating together with the planetary frame, it clings to the container and scrape the
materials on the wall off continuously. The container inner wall is precisely lathed and then mirror polished to ensure the
scraper can scrape all materials sticking to the wall off without residue, increasing the mixing effect.
Customized options
Different options are available such as explosion-roof type, closed type, heating type, with PLC intelligent control type, etc..
Material can be customized to be SS316L or special Spraying materials.
Model |
Work volume (L) |
Mixing power (kw) |
Revolve speed (rpm) |
Rotate speed (rpm) |
Scraper speed (rpm) |
Dispersing power (kw) |
Dispersing speed (rpm) |
Lifting mode |
Lift (mm) |
Hydraulic power (kw) |
Vacuum pump power (kw) |
SXJB-2 |
1.6 |
0.75 |
0-65 |
0-170 |
0-170 |
0.75 |
0-2930 |
Hydraulic lifting |
300 |
0.75 |
0.37 |
SXJB-5 |
4 |
1.5 |
0-65 |
0-170 |
0-170 |
1.1 |
0-2930 |
Hydraulic lifting |
350 |
0.75 |
0.37 |
SXJB-8 |
5 |
1.5 |
0-65 |
0-170 |
0-170 |
1.5 |
0-2930 |
Hydraulic lifting |
300 |
0.75 |
0.37 |
Remark:
*Capacity is tested based on the materials viscosity 200,000cps; The model selection shall be based on the data such as
the materials viscosity, characteristic etc.
* If the working condition is high temperature, high pressure, flammable, explosive, corrosive or others, you must provide
detailed data for our engineer to customize specially.
* If any change in the above table, subject shall prevail without notice.
* The table cannot include all products, please contact with our sales engineers for more information.
