Tri-shaft Multi-function Dispersing and Mixing Vessel
Introduction:
Multi-functional Tri-shaft Mixer is a product with dispersing, emulsifying, stirring functions developed on the basis of Dual Shaft Hydraulic Lifting mixer. The product has a good adaptability of high viscosity and thixotropy material; A variety of optional mixing ways, conventional such as anchor, butterfly, frame, etc.; It has so strong adaptability that emulsion, dispersion and mixing can be simultaneously realized, and can be customized by the different requirement of materials characteristic and production process of the customer.
Advantages
1.High mixing efficiency, excellent product quality
Multi-functional Tri-shaft mixer is mainly used in stirring and mixing of viscous material, the collocation of the tri-shaft stirring forms (dispersing +emulsifying +stirring, dispersing +dispersing+ stirring, stirring +stirring +stirring) to mix or stir the viscous materials single shaft mixer fails to mix; Its mixing efficiency is faster than dual shaft mixer, and the mixing effect is better.
2. Safe and convenient operation
Adopt hydraulic cylinder as lifting actuators. Control the mixer up, stop and down through controlling the valve, simple operation with high stability; Different clamping type (Belt Clamping, Manual Rotation Clamping, Pneumatic Clamping) are optional for fixing the mixing tank to prevent any possible accident due to tank displacement.
3. Various installation ways
With compact structure, the machine can be floor type, platform type. Tank working with the mixer can be removable type or fixed type
4. Customized options
Different options are available such as explosion-proof type, closed type, with lifting cover type,co-axial/dual shaft compound, multi-tanks type, mounted on kettle type, etc.. Material can be customized to be SS304 SS321 SS316L .
Specifications
Model |
Dispersing Power (kw) |
Dispersing Speed (rpm) |
Mixing Power (kw) |
Mixing Speed (rpm) |
Mixing Power (kw) |
Mixing Speed (rpm) |
Material |
Capacity (L) |
Hydraulic Power (kw) |
Lift (mm) |
SJBD-100 |
3 |
0-2880rpm |
2.2 |
0-85rpm |
2.2 |
0-350rpm |
SS304SS316L Stainless Steel |
≤40 |
1.5 |
700 |
SJBD-200 |
7.5 |
0-1450rpm |
4 |
0-85rpm |
4 |
0-350rpm |
SS304SS316L Stainless Steel |
≤160 |
2.2 |
800 |
SJBD-300 |
11 |
0-1450rpm |
7.5 |
0-61rpm |
7.5 |
0-250rpm |
SS304SS316L Stainless Steel |
≤240 |
3 |
900 |
SJBD-500 |
18.5 |
0-1450rpm |
11 |
0-61rpm |
11 |
0-250rpm |
SS304SS316L Stainless Steel |
≤400 |
4 |
1000 |
SJBD-800 |
30 |
0-1450rpm |
18.5 |
0-52rpm |
18.5 |
0-200rpm |
SS304SS316L Stainless Steel |
≤640 |
5.5 |
1100 |
SJBD-1000 |
37 |
0-1450rpm |
22 |
0-52rpm |
22 |
0-200rpm |
SS304SS316L Stainless Steel |
≤800 |
7.5 |
1200 |
SJBD-1300 |
45 |
0-1450rpm |
30 |
0-52rpm |
30 |
0-200rpm |
SS304SS316L Stainless Steel |
≤1000 |
7.5 |
1300 |
SJBD-1500 |
55 |
0-1450rpm |
37 |
0-41rpm |
37 |
0-160rpm |
SS304SS316L Stainless Steel |
≤1300 |
11 |
1400 |
SJBD-2000 |
75 |
0-1450rpm |
45 |
0-41rpm |
45 |
0-160rpm |
SS304SS316L Stainless Steel |
≤1600 |
11 |
1600 |
