SFSD Series High-speed Disperser With Multi-vessels

SFSD Series High-speed Disperser With Multi-vessels thumbnail-1
SFSD Series High-speed Disperser With Multi-vessels photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Mixer Type:
Other, dispersing disc
Product Type:
Paint
Contact Supplier Request Quote Chat Now
Shanghai Siehe Mechanical & Electrical Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Mixer Type Other, dispersing disc
Product Type Paint
Application Other, Liquid-Liquid, Liquid-Solid
Additional Capabilities Other, dispersing, mixing, dissolving
Place of Origin Shanghai, China
Brand Name SIEHE
Model Number SFSD
Max. Loading Capacity 20~10000L
Voltage 380V/50HZ(can be customized)
Power(W) 7.5Kw~132Kw
Dimension(L*W*H) accordingly
Certification CE, ISO
Warranty 12 months warranty, life time maintainance
After-sales Service Provided Engineers available to service machinery overseas
SFSD Series High-speed Disperser with Multi-vessels
 SFSD Series High-speed Disperser with Multi-vessels
 Working Principle:
High-speed Disperser is to dissolve, disperse and mix materials with different viscosity. Through the very high peripheral tip speed of the toothed disc, the strong shearing, crashing and friction forces generated between the materials and toothed disc disperse, dissolve and mix the materials efficiently. The large stress forces break down the agglomerates into the liquid or paste suspension.
Main Features:
1.It is with manual or electric steering system to adjust the working position to realize one machine working with several vessels. It steers flexibly, easy operation and convenient.  It increases utilization rate greatly and reduces equipment investment, saves space. It can be platform type or floor type.
2.Little air absorption during mixing and dispersing process.
3.It disperses and dissolves materials to smaller particle size efficiently.
4.No dead corner during mixing. Easy to clean, wide capacity range, various speed control, stable operation, low noise and long-time continuous operation.
Technical Parameter:

Model

Capacity
(L)

Power
(kw)

Speed
(rpm)

Disc .Dia
(mm)

Lifting
(mm)

Weight
(kw)

SFSD-7.5

≤400

7.5

0-1450

230

900

0.55

SFSD-11

≤500

11

0-1450

250

900

0.55

SFSD-15

≤700

15

0-1450

280

900

0.55

SFSD-18.5

≤800

18.5

0-1450

300

1100

0.75

SFSD-22

≤1000

22

0-1450

350

1100

0.75

SFSD-30

≤1500

30

0-1450

400

1100

0.75

SFSD-37

≤2000

37

0-1450

400

1600

1.1

SFSD-45

≤2500

45

0-1450

450

1600

1.1

SFSD-55

≤3000

55

0-1450

500

1600

1.1

SFSD-75

≤4000

75

0-950

550

1800

2.2

SFSD-90

≤6000

90

0-950

600

1800

2.2

SFSD-110

≤8000

110

0-950

700

2100

3

SFSD-132

≤10000

132

0-950

800

2300

3



Remarks:



*The above listed Max. processing capacity is calculated as per water as medium. The model  selection should depend on the comprehensive factors such as materials viscosity, specific gravity etc.

*If works under special environment such as high temperature, high pressure, explosive, combustible, corrosive etc, correct data is required for correct model selection.

*If any changes of the data and picture,no further notice is provided.Correct parameter is based on the real object provided.

*The sheet is not including all the products.To know more information,Pls feel free to contact our sales engineers.
