Liquid Water Based paint production equipment
SIEHE waterbased production equipment ranges from single equipment with 500T/year capacity to complete production line with 100,000 ton/year capacity. We have successfully serviced customers specialized in waterbased paint, water dilutable coating, water dispersible paint(latex paint), water soluble alkyd resin, water soluble epoxy resin, inorganic polymer water-based resin, etc..
Working Principle:
Generally speaking, water-based paint production process contains following steps: batching, dispersing, milling, tinting, filtering and filling.
Batching and conveying: liquid batching adopts pumps, flow meter; powder batching adopts weighing system and air conveying; additives batching adopts weighing method.
Dispersing: the first step to make paste. Powder material is equably dispersed into liquid by high speed disperser which generates uniform white paste without aggregation.
Milling: second step of making paste. White paste are ground to required fineness by German-tech basket mill.
Tinting: emulsion, color paste and additive are added into paste and mixed by single shaft or multi-functional mixer in tinting kettle.
Filtering: impurities are removed with the help of bag type filter or self-cleaning filters.
Filling: filtered product are filled whose specification is normally 10-25kg. Semi-auto or automatic filling machine are optional.
WHY US
| Good fineness and High Stability |
Dispersing and milling all-in-one machine basket mill is applied in plant as milling device which shows good products withgood fineness, high stability, small chromatism and less pollution. |
| Environmentally-friendly and Safe Operation |
Products are manufactured in totally closed flow line production surroundings, there is no dust in workshop which reduces operators’ workload and improves efficiency to large extent. |
| Wide Range of Products and Easy to Change and Clean |
Tinting system is able to produce and tint paint products in high, middle, low viscosity and easy to clean. Multi-function tinting kettle is optional to manufacturing high-build coatings, such as Gigging paint, elastic coating, putty and etc. |
| Highly Automatic |
Powder and liquid storage and batching system, automatic filling system, PLC control system are optional according to process to realize the automatic produce and remote control. |
