EN60335 Iisted 12V 3A US Wall-mounted ac dc Power Supply

Name: EN60335 Iisted 12V 3A US Wall-mounted ac dc Power Supply
Brand: LYD`
SKU: 100378647
Availability: InStock

US$ 1 - 99 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

LYD`

Model Number:

LYD1203000

Shenzhen Lianyunda Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name LYD`

Model Number LYD1203000

Output Type DC

Connection Desktop

Output power range	12v3A
Input Rated Voltage	100Vac~240Vac
Input Frequency Range	50Hz~60Hz
Input Current	less than 0.5A
Input Inrush Current	less than 50A
Efficiency	82%(MIN)at Rated Voltage
DC Output Voltage	12v± 5%
DC Output Current	3A (Optional)
DC Output Power	36w (optional)
Leakage Current	less than 5mA
Standby power	less than 0.5w
Ripple and Noise	less than 120Mv at full road with 20MHz bandwidth
Turn On Delay Time	less than 3S (AC:110V and full load)
Certificates	CE GS UL/CUL FCC ROHS SAA PSE TUVGS KC CLASS2 UL1310
Dielectric Voltage	A IEC320 three pin input---output(FG)3000Vac one minute
Safety protection	output voltage protection (150%-180% rated output current)
	output current protection (150%-180% rated output current)
	short current protection
Operating Temperature	-10°C - +45°C
Storage Temperature	-20°C - +40°C
Safety Standard	EN60950-1 UL60950-1 ESD (EN61000 3-3)
	CAS (60950 ITE/TE) FCC Part 15 subpart B Class B
	ISO 9001: 2008
