3Mpa High Pressure Compressor

Name: 3Mpa High Pressure Compressor
Brand: YUKUN
SKU: 100286233
Availability: InStock

Zhengzhou Yukun Machinery Equipment Co., Ltd.

US$ 10,000 - 100,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Other, Piston, ZW type

Configuration:

Stationary

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, Piston, ZW type

Configuration Stationary

Power Source AC Power

Lubrication Style Oil-free

Mute No

Place of Origin Henan, China

Brand Name YUKUN

Model Number ZW-1/(4-6)-30

Voltage 380V

Dimension(L*W*H) 1500x650x1350mm

Weight 950kg

Certification ISO9001:2000

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

3Mpa high pressure compressor

High pressure compressor

High pressure compressor is a device designed specially to compress nitrogen gas for storage;
High pressure compressor is generally reciprocating types with the most common being guided piston/metal diaphragm;
High pressure compressor is used to compressor the gas to enormous pressures,often in excess of 40,000PSI, so that it maybe stored in usable amounts high pressure compressor
The structure of high pressure compressor includes1 stage,2 stage,3 stage,4 stage to meet the client's different demands.

Parameters of high pressure compressor

Nitrogen compressor Technical Parameter
Model	Medium	Capacity (m³/min)	Inlet Pressure (Mpa)	Outlet Pressure (Mpa)	Power (KW)	Overall Dimension (mm)	Weight (KG)
ZW-4.2/8-10	Nitrogen	4.2	0.8	1	30	1500x650x1350	1000
ZW-0.8/6-30	Nitrogen	0.8	0.6	3	30	1600x750x1150	980
ZW-0.5/6-16	Nitrogen	0.5	0.6	0.6	11	1550x700x900	540
ZW-0.34/8-30	Nitrogen	0.34	0.8	3	11	1550x700x900	480
ZW-0.2/6-16	Nitrogen	0.2	0.6	1.6	4	1285x590x900	320
ZW-0.83/(2-5)-25	Nitrogen	0.83	0.2-0.5	2.5	22	1400x1196x940	1250
ZW-1/6-25	Nitrogen	1	0.6	2.5	30	1500x650x1500	700
ZW-1/(4-6)-30	Nitrogen	1	0.4-0.6	3	30	1500x650x1350	950
ZW-1.2/5-10	Nitrogen	1.2	0.5	1	15	1600x800x1150	840
ZW-0.2/3-25	Nitrogen	0.2	0.3	2.5	5.5	1305x700x900	450
