Made in China deep cycle gel solar battery 12v 150ah

FOB Price

Negotiable / Piece

500 Pieces(Min.Order)

Supply Ability 100000 Piece / Pieces per Month
Port Shenzhen/Guangzhou
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	MATRIX
Model Number	MNG 150-12	Usage	Other, Solar system,Wind Power System,Auto Control Sytem
Voltage	Other, 12v	Sealed Type	Sealed
Maintenance Type	Free	Size	486171233mm
Weight	42.3kg	Nominal Capacity	150ah

Product Description

Made in China deep cycle gel solar battery 12v 150ah

Product Description

Brand: Matrix/OEM

Nominal Voltage: 12v

Nominal Capacity: 150Ah

Dimension: 486*171*233mm

Weight: 42.3kg

Terminal Type: T11/T19

Design life: 15-18 years

Warranty: 3 year

Minimum order: 50PCS

Delivery: 15 days upon order confirm

Payment: by T/T or by L/C

OEM service acceptable

We are a profession manufacturer and exporter for Lead acid battery and GEL battery. We can supply you all models of lead acid /GEL battery with good quality and competitive price. If you are looking for sealed lead acid battery, Just email me with inquiry details.

We are welcome to your inquiry in any time!

Battery Construction:

Battery Model	MNG 150-12 12V150AH
Designed Floating Life	Up to 12 Years
Capacity (25℃)	20HR(7.50A,10.8V)	10HR(15.0A,10.8V)	5HR(25.5A,10.8V)	1HR(83.5A,10.5V)
Capacity (25℃)	150.0AH	150.0AH	127.5AH	83.5AH
Dimensions	Length	Width	Height	Total Height
Dimensions	486mm (19.13inch)	171mm (6.73inch)	233mm (9.17inch)	243mm (9.57inch)
Approx. Weight	42.30Kg (93.27 lbs)
Internal Resistance	Full charged at 25℃:≤6.3mΩ
Self Discharge	2% of capacity declined per month at (25℃)
Capacity Affected	40℃	25℃	0℃	-15℃
by Temp.(20HR)	102%	100%	85%	65%
Charge Voltage(25oC)	Cycle use		Float use
Charge Voltage(25oC)	14.4-14.6V(-30mV/℃), max. Current: 36.0A		13.6-13.8V (-20mV/℃)

Constant Current Discharge(CC,Unit:A) at 25℃(77℉)
F.V/Time	5Min	10Min	15Min	30Min	1Hr	2Hr	3Hr	4Hr	5Hr	8Hr	10Hr	20Hr
9.6V	480	317	255	171	90	52.5	38.6	30	24.8	17.55	15.75	8.51
10.2V	465	286	240	163.5	84.6	50.1	37.5	29.3	24.3	17.1	15.45	8.25
10.5V	450	255	210	153	81.9	48.9	36.6	28.8	24	16.95	15.15	8.22
10.8V	434	241	195	141	79.2	47.7	35.7	28.4	23.4	16.5	15	8.1
11.1V	419	226	180	126	76.5	46.5	34.5	27.6	22.8	16.05	14.25	7.65
Constant Power Discharge (CP,Unit:W) at 25℃(77℉)
F.V/Time	5Min	10Min	15Min	30Min	1Hr	2Hr	3Hr	4Hr	5Hr	8Hr	10Hr	20Hr
9.6V	4958	3380	2736	1839	972	576	429	338	281	201	182	98.9
10.2V	4969	3189	2689	1835	957	577	434	340	283	200	182	96.8
10.5V	4916	2906	2398	1761	948	567	426	337	281	199	179	86.3
10.8V	4867	2776	2250	1634	922	559	421	335	277	196	178	85
11.1V	4754	2612	2099	1474	900	550	410	329	272	192	172	80

Certifications

ISO CE
