NJ2044XJHG IVECO 4X4 LHD Troop Ambulance Diesel SL

  NJ2044XJHG IVECO 4WD LHD Troop Ambulance

Standard Configurations

1)        NJ2044XJHG IVECO 4WD vehicle: 1

2)        Independent A/C in cab room and patient compartment: 1set

3)        Blue alarm lamp and siren: 1set

4)        Transfusion support: 1set

5)        Medicine and instrument cabinet in patient compartment: 1set

6)        Oxygen bottle: 10L, 2pcs

7)        Oxygen terminal: 1set

8)        Electric Ventilation fan system:1set

9)        Push-lift stretcher:1set

10)    Folding stretcher: 1set

11)    Bench bed:1set for 3 persons

12)    Partition wall with observation window:1 set

13)    Illumination light in patient room:1set

14)    Folding chair:1set

15)    Vice driver seat:1set

16)    Garbage bin: 1pc

17)    Inverted power supply: 1set

18)    Medical equipment cabinet:1set

19)    Non-contact interphone: 1 set

Technical Parameters of chassis and engine:

1)        Model of vehicle: NJ2044XJHG, equipped with air conditioner and radio

2)        Chassis model: NJ2044GYCCP

3)        Overall dimensions (mm): 4855×2080×2435 (2635, including warning light)

4)        Patient's compartment dimensions (mm): 2465×1820×1500

5)        Complete vehicle curb mass: 3000kg

6)        GVW: 4450kg

7)        Wheelbase (mm): 2800

8)        Wheel tread (mm front/rear): 1670/1670

9)        Min. ground clearance (mm)(front/back): 235

10)    Min. turning radius (m): 6

11)    Approach/departure angel: 35/32.5

12)    Max. gradeability (%): 60

13)    Fording depth (mm): 700

14)    Trench crossing (mm): 550

15)    Maximum speed(km/h): 105

16)    Fuel tank capacity (L):75

17)    Fuel: diesel

18)    Fuel system: turbocharging

19)    Wheel rim: hub type

20)    Fuel consumption (L/100km) (direct gear,50km/h uniform speed): ≤13

21)    Emission standard: Euro IV

22)    Tire: 255/85R16LT 8PR

23)    Brake system: front disc / rear drum

24)    Engine Model: SOFIM8142.43S4

25)    Engine type: in-line, 4 cylinders, 4 strokes,water-cooled, overhear camshaft, direct Injection turbocharged inter-cooled diesel engine

26)    Displacement (ml.): 2798

27)    Engine power (kw/rpm): 95kw/3600rpm

28)    Max. torque(Nm/rpm): 269N.m/1900rpm

29)    Suspension (front/rear):Torsion bar independent suspension / steel spring

30)    Front overhang / rear overhang (mm): 1000/1055

31)    Gearbox: manual 5 speed, 5 forward gear, 1 reverse gear
