Specifications
ATC cnc router1 whole steel structure
2 HIWIN square linear guideway
3 Auto tool changing
ATC cnc router /HSD 9kw/Taiwan 8 tools changer/6 sec change
Our automatic tool changing machining center consists of two models with 8 cutting tool positions in a row and bamboo hat-like magazine respectively. Our products feature a fast and stable performance. The speed to change the cutting tool is very fast, while the maintenance is simple and failure rate is low. Our products adopt powerful, state-of-the-art CNC machining system. It could receive data from U disk or network connection. With a servo motor, our products could achieve high precision processing, smooth running and produce little noise.
Our automatic tool changing machining center is equipped with a high-precision guideway to provide smooth operation and high precision, which can also effectively extend the life of our products. Industrial-grade ball screw is used in the Z-axis of the products to make sure accurate positioning. Adsorption countertops, rotating unit and cleaning device are optional for our machines to make a great place to work. In addition, our products are compatible with multiple CAD / CAM design softwares, such as TYPE3, Artcam, JD, Wentai carving, UG, MasterCAM, PowerMill and others.
APPLICABLE INDUSTRIES
1, Arts & Crafts industry: Sculpture making of arts & crafts such as process relief, shadow carving, craft ornaments, car accessories and so on.
2, Furniture industry: Solid wooden doors, composite doors, cabinet doors, interior doors, sofa legs, headboards, antique furniture and superficial flower-shaped engraving of various plate-type furniture and disposable finishing of process such as unlocking holes.
3, Mould industry: Casting wooden molds, precise making for disappeared mold casting foam, food molds (such as: moon cake molds).
4, Architectural model making
5, Advertising industry: Engraving and making for acrylic cutting and engraving, acrylic plastic model making, badges and a variety of logo signs
6, Decorated industry: Variety of decorations engraving process such as decorative murals, screens, decorative patterns, three-dimensional wave boards, sound-absorbing panels and so on.
7, Semi-finished products processing of industrial equipment accessories Deep processing for semi-finished products such as countertops of industrial sewing machines and electrical cabinets.
8, Musical instrument industry:
Headstock processing, guitar semi-finished products processing, surface sculpture and three-dimensional curved surface making of various musical instruments’ decorative patterns
APPLICABLE MATERIALS
Wood, acrylic, PVC, density boards, artificial stones, organic glass, plastics and soft metal sheets such as copper and aluminum
PRODUCT FEATURES
1. Gantry machining center is specially designed for middle and-high-end clients with higher automation degree requirements. It’s suitable for high-volume, 24-hour processing non-metallic, copper, aluminum and aluminum extrusion profiles and so on.
2. High stability: Industrial production models, heavy-duty all-steel structure welding, tempering vector effect processing, solid and uneasy deformation;
3. High-quality parts: Taiwan control system, high-precision spindle ceramic bearing , low noise, and long service life. Imported linear guide; German ball screw, big loading capacity, high precision for cutting; servo system, high pulling torque has improved the safety of systems engineering;
4. Modular structure design: elect various processing conversion head configuration, can carry on carving, engraving, cutting and milling work;
5. Easy and safe modes of operation: Advanced documents pre-processing functions ensure running speed and accuracy;
6. Row automatic tool changing system: 8 tools’ magazine capacity;
7. High adhesion vacuum suction device;
8. Software Compatibility: compatible with the processing code generated by a variety of CAD/CAM design software such as type3/artcam/castmate/Wentai
9. Improving oiling lubrication system extends the machine’s service life.
SPECIFICATIONS
Model |
FASTCUT-25H |
Max. Processing Size |
1300mmX2500mmX200mm |
Idle Speed |
≥30000mm /min |
Spindle Power |
5.5KW variable frequency spindle, 18000 rev/min(larger power is available) |
Spindle Cooling |
Air cooling / water cooling (Italy HSD spindle optional) |
Magazine |
8 cutting tool positions in a row or bamboo hat-like magazine (3-12 positions are optional) |
Mechanical Precision |
0.025mm |
Compatible Instructions |
G-CODE, PLT, mmg, UG, ENG, HPGL, etc. |
Power consumption |
4KW |
Voltage |
AC380V |
Size |
2100mmX3200mmX1950mm |
Net weight |
1800KG |
Remark |
We can customize the model for any processing size |
SAMPLES
MACHINE PARTS PICTURES
FACTORY SHOW
PRODUCT CERTIFICATE
COOPERATIVE CUSTOMERS
COOPERATIVE SUPPLIERS
COMPANY ADVANTAGES
1, First-class factory meets international production plant's standard, ten years' manufacture and export experiences
2, Own most advanced domestic cnc machining production equipments
3,20 professional high-end R&D technical staff, and can provide multiple languages and real-time online technical support
4,5-9 days machine production time, one year warranty and lifetime free maintenance
5,OEM and ODM services avaliable
6,Same quality, our price and service are better;Same price, our quality and service are better
7, with CE, FDA, SGS, ISO9000 certifications
PRODUCTION PROCEDURE
CONTACT US
FAQ
In order to help you choose the best suitable machine, please try to reply my questions below, thanks
Q1: What about your material , wood or acrylic or ?
Q2: The size of your mateiral , length ? Width and thickness?
Q3: Do you want to cut or engrave your material ? Or both cut&engrave ?
Q4: What machining effection do you want to get ? It is better you can send sample pictures to me .
Q5: The machine choose 220v or 110v or ?
Q6: what about your nearest sea port
